1 catalog sizesThe square-profile hinge shown in the catalog. Original size notation is retained for confirmation.
Industrial weld-on hinges
Adjustable Weld-On Hinges
An adjustable hinge construction with three published catalog size and weight records. Send the required installation details for review.
- Published sizes
- 3 catalog entries
- Hinge family
- Adjustable typeAdjustable construction
- Published sizes
- 3 catalog entries
- First listed size
- Φ20x25x140mm
- Last listed size
- Φ25x30x140mm
The product
Product overview.
The catalog photograph shows an adjustable hinge construction with a visible adjustment screw. Three complete compound size strings and corresponding product weights are published.
No adjustment range is stated in the source. Provide the installation geometry and required adjustment details with the inquiry so they can be reviewed.
Original catalog data
Available Sizes & Weights
Sizes reproduced as catalogued. Weight is product mass, not load capacity.
| Catalog size | Weight (g) | Choose a size for your inquiry |
|---|---|---|
| Φ20x25x140mm | 354 | Select size |
| Φ22x27x140mm | 416 | Select size |
| Φ25x30x140mm | 525 | Select size |
Each row is a published catalog entry. Choose a size to add the exact notation to your inquiry.
Custom hinge requirements
Supports Customization
The catalog identifies customization support for this product family. Send your required dimensions or technical drawing so the requirement can be reviewed.
Discuss Your Requirement Explore custom manufacturing
From the factory
Manufacturing & Quality
Lathe Processing
Lathe processing for manufactured hinge components.
Automatic Punching
Automatic punching as part of metal component processing.
Mass Assembly
Assembly and standardized product handling support production.
In-Process Inspection
Product checking tools are used during the production process.
Other constructions
Before you inquire
Useful answers.
Which adjustable weld-on hinges are listed?
The source publishes three compound size strings and product weights; it does not publish an adjustment range. Only the individual published records shown in the table are presented as catalog options.
Can I request a custom configuration?
The catalog identifies customization support for this family. Send the required dimensions or a technical drawing for review; unlisted materials, finishes and performance requirements need confirmation.
Can I send a technical drawing?
Use the file fields in the inquiry form to attach a drawing or reference image. Include the dimensions, installation details and any requested changes. Check the form's submission result after sending.
What information should I provide for a quotation?
Include the hinge family, exact catalog notation or required dimensions, estimated quantity, application and company contact details. Add your drawing and packing requirements where available.
